KFSE-116-8
Broaching Standoffs - Types KFE, KFSE - Unified
Part Aliases: Penn Engineering 90-09115-02
Enhance your assembly process with our Broaching Standoffs, available in Types KFE and KFSE for Unified specifications. Crafted from durable 300 Series Stainless Steel with a passivated finish, these standoffs ensure reliable performance and corrosion resistance. Designed for easy installation, they provide sturdy support in various applications. Compliant with RoHS standards, they are a sustainable choice for your projects. Watch our animation for a closer look at their features and see how they can streamline your workflow. Elevate your assembly game with these essential components.
| Product Category: | |
| Manufacturer: | Penn Engineering |
| Manufacturer Part Number: | Penn Engineering KFSE-116-8 |
| Material: | 300 Series Stainless Steel |
| Finish/Coating: | Passivated |
| Animation: | View Animation |
| Part Aliases: | 90-09115-02 |
| SKU: | PEMKFSE-116-8 |
| Long Description: | Type KFE and KFSE - Broaching standoffs, threaded or unthreaded for stacking or spacing. |
| For Use in Sheet Hardness: | HRB 70 / HB 125 or Less|PC Board |
| Length Code: | 8 |
| Min. Sheet Thickness: | .060 in |
| Thru-Hole Code: | 116 |
| A (Shank) Max.: | .060 in |
| C ± .003: | .184 in |
| E ± .005: | .219 in |
| Hole Size in Sheet + .003 - .000: | .166 in |
| L - Length ± .005: | .250 in |
| Min. Dist. Hole C/L to Edge: | .17 in |
| Thru Hole + .004 -.003: | .116 in |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
